Model: DG600 Product Name: Slides for vertical center opening door
Attention

1.There is up/down/left/right directions when install it.

2.Mounting screws in the inner side of the door frames.

3.First install the up door sheet and the down door

  sheet according to the installation sizes, and

  then install the door body.

4.The door width should not exceed 2m. The minimal

  thickness of the doors should reach 16MM.
5.The weight of the up door sheet and the down door
  sheet should  be similar. The weight of the up door

  sheet might be a little bi  more than the down door

  sheet.

Load Capacity: Max 30KGS

Adjustable Height: 8MM


Installation diagram

Download

Video
